| DHC-800 |
|
|
- Provides an answer to the health and safety recommendations for manual lifting.
- Powerful permanent magnet DC motor with sustainable performance
- Automatic,double cone brake.
- Compact design and make installation quick and easy.
- Never use winch to carry people. Never lift heavy stuffs to pass over people’s head.
|
|
|
|
|
| SPECIFICATION |
| Line pull: 362kgs/800lbs |
| Motor: 1.0HP |
| Gear Train: Three stage |
| Gear Ratio: 187:1 |
| Freespooling Clutch: Rotating ring gear |
| Wire Rope Size: Φ3/16"×49.5'(Φ4.8mm×15m) |
| Drum Size: Φ2.3"×5.2"(Φ59mm×131mm) |
| LINE PULL |
| Layer of Wire Rope |
Max Line Pull |
| 1 |
800lbs/362kgs |
| 2 |
690lbs/313kgs |
| 3 |
600lbs/272kgs |
| 4 |
550lbs/249kgs |
| LINE SPEED AND AMP DRAW(1st layer of rope on the drum) |
| Load |
Line Speed |
AMP Draw(12V) |
AMP Draw(24V) |
| No Load |
13.5FPM/4.1MPM |
25 |
14 |
| 400lbs/184kgs |
11.5FPM/3.5MPM |
43 |
27 |
| 800lbs/362kgs |
10.8FPM/3.3MPM |
60 |
35 |
|
|
|
|
DIMENSIONS(mm)
| STANDARD ACCESSORIES |
| Controller |
| Control Unit |
| Mounting Hardware |
| Handsaver Strap |
| Hook |
| 4 Way Roller Fairlead |
| Wire Rope |
| |
| PACKAGE |
| Winch weight : 14kgs/30.8lbs |
| Gross Weight : 15kgs/33lbs |
| Box Dimension : 430×230×235 mm(16.9"×9"×9.25") |
| |
|
| |
|
|
