| THS-15 |
|
|
- Smooth running over the entire speed range.
- Highly efficient, constant operating torque motor.
- Rotating ring gear frees pooling clutch is a pull and turn design for rapid wire rope payout.
- Freespooling. Power in/out. Mechanical lock. Stainless steel tie bars . Reversible mounting.
- Variable speed hydraulic winch.
|
|
|
|
|
| SPECIFICATION |
| Line pull: 6,804kgs/15,000lbs |
| Operation Pressure: 175bar/2,537psi |
| Max Oil Flow: 15.9g/min(60l/min) |
| Gear Ratio: 43.5:1 |
| Wire Rope Size: Φ8/17"×83'(Φ12mm×25m) |
| Drum Size: Φ3.5"×8.1"(Φ89mm×206mm) |
| Gear Train: Planetary |
|
| LINE PULL Line Speed |
| Layer of Wire Rope |
Max Line Pull Line Speed |
| 1 |
15,000lbs/6,804kgs 6.3MPM/20.6FPM |
| 2 |
12,085lbs/5,482kgs 7.5MPM/24.6FPM |
| 3 |
10,118lbs/4,589kgs 8.8MPM/28.9FPM |
| 4 |
8,702lbs/3,947kgs 10.2MPM/33.5FPM |
|
| |
|
| DIMENSIONS(mm) |
| |
|
| |
| STANDARD ACCESSORIES |
| Over Center Valve TA-0918 |
| Coupling TA-0928 |
| Hawse Fairlead TA-0921 |
| Wire Rope |
| Hook TA-0401 |
| |
| OPTIONAL ACCESSORIES |
| High Pressure Hose TA-0929 |
| Base Plate TA-0927 |
| |
| PACKAGE |
| Winch weight : 68kgs/150lbs |
| Gross Weight : 70kgs/154lbs |
| Box Dimension : 710×255×450mm(27.9"×10"×17.7") |
| |
|
| |
|
|
