ELECTRIC WINCHES

DHC-800 SR

· Provides an answer to the health and safety recommendations for manual lifting.

· Powerful permanent magnet DC motor with sustainable performance.

· Automatic,double cone brake.

· Compact design and make installation quick and easy.

· Never use winch to carry people. Never lift heavy stuffs to pass over people’s head.

Detailed Data:

SPECIFICATION

Line pull: 362kgs/800lbs

Motor: 1.0HP

Gear Train: Three stage

Gear Ratio: 187:1

Freespooling Clutch: Rotating ring gear

Synthetic Rope Size: Φ1/5"×49.5'(Φ5mm×15m)

Drum Size: Φ2.3"×5.2"(Φ59mm×131mm)

LINE SPEED AND AMP DRAW(1st layer of rope on the drum)
Load	Line Speed	AMP Draw(12V)	AMP Draw(24V)
No Load	13.5FPM/4.1MPM	25	14
400lbs/184kgs	11.5FPM/3.5MPM	43	27
800lbs/362kgs	10.8FPM/3.3MPM	60	35

DIMENSIONS(mm)

STANDARD ACCESSORIES

Controller

Control Unit

Mounting Hardware

Handsaver Strap

Hook

4 Way Roller Fairlead

Synthetic Rope

PACKAGE

Winch weight : 11kgs/24.2lbs

Gross Weight : 12kgs/26.4lbs

Box Dimension : 430×230×235 mm(16.9"×9"×9.25")
