| THS-12 |
|
|
· Smooth running over the entire speed range.
· Highly efficient, constant operating torque motor.
· Rotating ring gear frees pooling clutch is a pull and turn design for rapid wire rope payout.
· Freespooling. Power in/out. Mechanical lock. Stainless steel tie bars . Reversible mounting.
· Variable speed hydraulic winch. |
|
|
|
|
| SPECIFICATION |
| Line pull: 5,443kgs/12,000lbs |
| Operation Pressure: 175bar/2,537psi |
| Max Oil Flow: 15.9g/min(60l/min) |
| Gear Ratio: 43.5:1 |
| Wire Rope Size: Φ7/16"×90'(Φ11mm×27.4m) |
| Drum Size: Φ3.5"×8.1"(Φ89mm×206mm) |
| Gear Train: Planetary |
|
| LINE PULL Line Speed |
| Layer of Wire Rope |
Max Line Pull Line Speed |
| 1 |
12,000lbs/5443kgs 7.0MPM/22.9FPM |
| 2 |
9,809lbs/4,449kgs 8.5MPM/27.6FPM |
| 3 |
8,294lbs/3,762kgs 10MPM/32.8FPM |
| 4 |
7,185lbs/3,259kgs 11.5MPM/37.7FPM |
|
| |
|
| DIMENSIONS(mm) |
| |
|
| |
| STANDARD ACCESSORIES |
| Over Center Valve TA-0918 |
| Coupling TA-0928 |
| Hawse Fairlead TA-0921 |
| Wire Rope |
| Hook TA-0401 |
| |
| OPTIONAL ACCESSORIES |
| High Pressure Hose TA-0929 |
| Base Plate TA-0927 |
| |
| PACKAGE |
| Winch weight : 65kgs/143lbs |
| Gross Weight : 68kgs/150lbs |
| Box Dimension : 710×255×450 mm(27.9"×10"×17.7") |
| |
|
| |
|
|
